Andere Panelgrößen und Leistungsklassen dieses Herstellers sind ab Lager und auf Anfrage erhältlich
Risen RSM108-9-435N 415-440 1500V Black Frame
| Modulleistung | 435 W |
| Zelltyp | N-Typ |
| Farbrahmen | Schwarzer Rahmen |
| Modultyp | Monofazial |
Produktdetails
| Series Name | RSM108-9-415N-440N |
| Series Power Range (Wp) | 415-440 |
| Model Name | RSM108-9-435N |
| Warranty Years | 15 |
| Primary (Years, % Output Power) | 30, 87.4 |
| Voltage at Maximum Power, Vmpp (V) At STC | 33.15 |
| Current at Maximum Power, Impp (A) At STC | 13.13 |
| Open Circuit Voltage, Voc (V) At STC | 39.47 |
| Short Circuit Current, Isc (A) At STC | 14 |
| Panel Efficiency (%) At STC | 22.3 |
| Temperature coefficient of Pmax (%/°C) | -0.3 |
| Temperature coefficient of Voc (%/°C) | -0.25 |
| Temperature coefficient of Isc (%/°C) | 0.046 |
| Maximum System Voltage (V) | 1500 |
| Series Fuse Rating (A) | 25 |
| Cell Number | 108 |
| Glass Type | High Transmission, Low Iron, Tempered ARC Glass |
| Frame Type | Anodized Aluminium Alloy |
| Junction Box Diodes | 3 |
| Junction Box Protection Class | IP68 |
| Connector Type | Risen Twinsel PV-SY02 |
| Cable Crosssection (mm²) | 4 |
| Cable Length (mm) | 350 |
| Height (mm) | 1722 |
| Width (mm) | 1134 |
| Depth (mm) | 30 |
| Weight (kg) | 22 |
